Moving Beam Drilling & Milling Machine

Name: Moving Beam Drilling & Milling Machine
Brand: MAXTURN MACHINERY
Price: 10000000 INR
Availability: InStock

Price 10000000 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Moving Beam Drilling & Milling Machine Specification

Product Type
Moving Beam Drilling & Milling Machine

General Use
Industrial Metal Drilling and Milling

Material
Mild Steel, Stainless Steel, Aluminum, Cast Iron

Type
Automatic CNC Gantry Milling Machine

Capacity
Heavy Duty, suitable for large and multiple work pieces

Weight (kg)
Approx. 12,000 kg or more

Computerized
Yes, CNC

Automatic
Yes

PLC Control
Integrated or Optional

Bar Feeder
Optional/Not Included

Power Source
Electric

Power Consumption
Depends on model, typically 10~25 kW

Rigidity
High structural rigidity for precision machining

Voltage
380V/415V, 3 Phase

Motor
High-performance spindle and servo motors

Table Size
Variable, often 2000 x 4000 mm or custom

Spindle Speed
Up to 6000 RPM (Variable)

Axial Choice
XYZ Axis (3-axis or more)

Dimension (L*W*H)
Depends on model, ~6000 x 3000 x 3500 mm

Feature
CNC controlled, Automatic tool change, High precision

Color
White/Black with blue highlights

Control System
Siemens/Fanuc/Mitsubishi (Customizable)

Repeatability
0.01 mm

Worktable Load Capacity
Up to 5000 kg

Travel Distance
X: 4000 mm, Y: 2000 mm, Z: 800 mm (varies by model)

Max Workpiece Height
600 mm (Typical)

Lubrication System
Automatic centralized lubrication

Tool Magazine Capacity
24 Tools (Typical, can vary)

Application
Precision engineering, Aerospace, Heavy machinery.

Positioning Accuracy
0.02 mm

Interface
USB/Ethernet

Protection
Full enclosure with safety interlocks

Coolant System
Included, high-pressure pump

Spindle Taper
BT40/BT50

About Moving Beam Drilling & Milling Machine

CNC Moving beam drilling and milling machines feature a heavy-duty gantry frame with an adjustable, vertically moving crossbeam. Designed for large, complex workpieces like excavator arms and structural metal, this design accommodates various part heights without multiple clampings. It integrates hydraulic and electronic controls for multi-axis boring, tapping, and drillingBeam Drilling&Milling MachineMoving Beam Drilling&Milling Moving Beam Drilling&Milling MachineMachine

Exceptional Precision and Performance

This moving beam machine stands out for its superior accuracy, thanks to a positioning accuracy of 0.02 mm and repeatability of 0.01 mm. The CNC-controlled system ensures consistent machining of complex parts, fostering reliability in high-value manufacturing environments such as aerospace and heavy industry.

Versatile Machining Capabilities

With a variable table size and the ability to process large or multiple workpieces-handling weights up to 5000 kg-this machine accommodates mild steel, cast iron, aluminum, and stainless steel. Supported by automatic tool changing (BT40/BT50), high-performance spindle speeds up to 6000 RPM, and customizable axes, it adapts to diverse production requirements.

Advanced Operator Safety and Integration

Safety is reinforced through a fully enclosed structure with interlock mechanisms, while user-friendly controls from Siemens, Fanuc, or Mitsubishi facilitate smooth operation. USB or Ethernet connectivity enables effortless data management and remote monitoring, enhancing productivity and process oversight in industrial spaces.

FAQ's of Moving Beam Drilling & Milling Machine:

Q: How does the automatic tool changer improve machining efficiency?

A: The automatic tool magazine, typically equipped with 24 tools, enables swift, seamless tool changes during operations. This minimizes downtime and allows for uninterrupted machining cycles, reducing manual intervention and boosting overall productivity for complex jobs.

Q: What materials and workloads can this machine handle?

A: Designed for industrial use, this equipment efficiently drills and mills mild steel, stainless steel, aluminum, and cast iron. Its robust worktable holds workpieces weighing up to 5000 kg, supporting large or multiple parts in heavy-duty applications.

Q: When should I choose this CNC gantry milling machine for my workshop?

A: Opt for this machine when high precision, large workpiece capacity, and automation are required-especially if your operations include aerospace, heavy machinery, or any industry where accuracy and reliability are paramount for complex, large-scale projects.

Q: Where is the machine most effectively deployed?

A: This moving beam CNC machine is ideal for deployment in advanced manufacturing facilities, aerospace component fabrication, industrial metalworking, and heavy engineering plants where stringent tolerances and efficiency drive success.

Q: What are the key benefits of integrated coolant and lubrication systems?

A: The included high-pressure coolant and automatic centralized lubrication systems actively manage heat and friction during operation, extending tool life, maintaining machining accuracy, and reducing maintenance downtime.

Q: How does the control system support customization and ease of use?

A: Users can select from Siemens, Fanuc, or Mitsubishi controls, each providing intuitive CNC interfaces and comprehensive function sets. These systems allow for full workflow customization, enabling seamless integration into existing production environments.
